一、沸石轉輪+RTO（蓄熱式氧化器）工藝:

　　1、 Zeolite Wheel+RTO (Regenerative Oxidizer) Process:

　　是一種的VOCs（揮發性有機化合物）廢氣處理技術，特別適用于處理大風量、中低濃度的有機廢氣。這套工藝結合了沸石轉輪的濃縮能力和RTO的氧化分解能力，實現了減排和經濟運行的目標。

　　It is an efficient VOCs (volatile organic compound) waste gas treatment technology, particularly suitable for treating high air volume, low to medium concentration organic waste gas. This process combines the concentration capacity of zeolite rotors with the oxidative decomposition capacity of RTO, achieving the goals of energy conservation, emission reduction, and economic operation.

　　沸石轉輪吸附濃縮:

　　Zeolite rotary adsorption concentration:

　　沸石轉輪是一種旋轉式的吸附裝置，其核心是由沸石分子篩組成的蜂窩狀結構。沸石具有高度的親水性和選擇性吸附能力，能夠從廢氣中捕捉并濃縮VOCs。沸石轉輪分為三個區域：吸附區、解吸（再生）區和冷卻區。

　　Zeolite wheel is a rotary adsorption device, with a honeycomb structure composed of zeolite molecular sieves at its core. Zeolite has high hydrophilicity and selective adsorption ability, which can capture and concentrate VOCs from exhaust gas. The zeolite wheel is divided into three zones: adsorption zone, desorption (regeneration) zone, and cooling zone.

　　1. 吸附區：低濃度的有機廢氣通過沸石轉輪的吸附區時，VOCs被沸石分子篩吸附，凈化后的氣體直接排放。

　　1. Adsorption zone: When low concentration organic waste gas passes through the adsorption zone of the zeolite wheel, VOCs are adsorbed by the zeolite molecular sieve, and the purified gas is directly discharged.

　　2. 解吸（再生）區：沸石轉輪旋轉到解吸區域時，使用高溫空氣（通常180-220°C）對沸石進行加熱，使吸附的VOCs脫附出來，形成高濃度的VOCs蒸汽。

　　2. Desorption (regeneration) zone: When the zeolite wheel rotates to the desorption zone, high-temperature air (usually 180-220 ° C) is used to heat the zeolite, causing the adsorbed VOCs to desorb and form high concentration VOCs vapor.

　　3. 冷卻區：脫附后的沸石通過冷卻區恢復吸附能力，準備再次吸附廢氣中的VOCs。

　　3. Cooling zone: The desorbed zeolite recovers its adsorption capacity through the cooling zone and is ready to adsorb VOCs in the exhaust gas again.

　　RTO蓄熱式氧化:

　　RTO Regenerative Oxidation:

　　RTO是一種的氧化處理設備，用于將濃縮后的高濃度VOCs氧化分解為二氧化碳和水。其特點是利用蓄熱體儲存和釋放熱量，大幅減少能源消耗。

　　RTO is an efficient oxidation treatment equipment used to oxidize and decompose concentrated high concentration VOCs into carbon dioxide and water. Its characteristic is the use of thermal storage to store and release heat, significantly reducing energy consumption.

　　1. 蓄熱氧化：濃縮后的VOCs蒸汽被送入RTO，通過蓄熱體預熱，然后在高溫（760-950°C）條件下，VOCs被氧化分解。

　　1. Thermal storage oxidation: The concentrated VOCs vapor is sent to RTO, preheated by a thermal storage body, and then under high temperature (760-950 ° C) conditions, VOCs are oxidized and decomposed.

　　2. 熱回收：RTO中的蓄熱體能夠吸收廢氣燃燒產生的熱量，并在下一循環中預熱進入的廢氣，大大減少了燃料的消耗。

　　2. Heat recovery: The thermal storage body in RTO can absorb the heat generated by the combustion of exhaust gas and preheat the incoming exhaust gas in the next cycle, greatly reducing fuel consumption.

　　沸石轉輪+RTO工藝的優勢在于，沸石轉輪可以將低濃度的大風量廢氣濃縮，降低RTO處理的氣量和能耗，使得整個系統更加經濟。同時，RTO的熱回收機制也進一步降低了運行成本。

　　The advantage of the zeolite wheel+RTO process is that the zeolite wheel can concentrate low concentration high-volume exhaust gas, reduce the gas volume and energy consumption of RTO treatment, and make the entire system more economical and efficient. Meanwhile, the heat recovery mechanism of RTO further reduces operating costs.
